wiring to the disturber

[johnnyb]

was wondering on the wire harness there is 2 wires that are cuddled with a heralded with a black and wight wire that go's the the disturber and was wondering where do the black and wight wire go to on the disturber
dose the black on go to the black
and wight go to the orange wire.

[kjones6039]

I think we will need to know a bit more about your car. ie. year, make, engine, etc

[johnnyb]

this wire in the wire harness with the wight ond black wire go's to a msd disturber wires



this is the msd disturder that i am running
http://www.jegs.com/i/MSD+Ignition/121/85501/10002/-1

[kjones6039]

That certainly helps. Since I'm not an MSD kind of guy, you'll have to wait for one of the MSD experts to drop by.

Sorry...........

Ken

[johnnyb]

anyone?

[kjones6039]

Even though I'm not familiar with your MSD distributor, maybe we can figure this out, but we'll need some additional information.

What version (processor, board, firmware etc.) MS are you connecting this to?
What type of coil do you plan to control?
What kind of sensor is installed in the MSD distributor?
Which pins are the black and white wires in your picture currently connected to on the MS?
Have you read the ignition section of the manual that applies to your particular version of MS?

Ken

[johnnyb]

Even though I'm not familiar with your MSD distributor, maybe we can figure this out, but we'll need some additional information.

What version (processor, board, firmware etc.) MS are you connecting this to-------------------]running the ms2[/url]
What type of coil do you plan to control? ------------- MSD HVC Ignition Coil
What kind of sensor is installed in the MSD distributor?-------------- HEI style distributor cap
Which pins are the black and white wires in your picture currently connected to on the MS?---------------------------24 is the gray one and 1is the black one.
Have you read the ignition section of the manual that applies to your particular version of MS?--------------------no cant find any info about it.

Ken

[Matt Cramer]

There's a couple things missing from your answers.

1. What board and firmware are on the MS2?
2. What SENSOR is in the MSD distributor? The distributor cap would not have a sensor.

[johnnyb]

There's a couple things missing from your answers.

1. What board and firmware are on the MS2?
2. What SENSOR is in the MSD distributor? The distributor cap would not have a sensor.

sorry the board is ms2 pcb v3.57
for the sensor i don't know but's its a locked out timing with a Magnetic Pickup

[Matt Cramer]

Ok, I was looking for "Magnetic pickup." The documentation calls this a VR sensor. Jumper it for VR input and connect the black and white wires to the sensor output. They can go either way, depending on what Ignition Input Capture you use. Either one will get an RPM, but only one will get a stable timing signal.

[johnnyb]

so off the disturber there is a orange/black and off the msd box its purple/green, on the mds the green is negative and the purple is postive.
when you plug them in to each other it go
(dis)orange-(msd)purple would be the wight wire off ms
(dis)purple-(msd)green would be the black wire off ms
so on the ms wiring harness i would put the black wire to the green/purple wire and the wight on to the orange/purple.

[johnnyb]

anyone
ttt

[Matt Cramer]

Did you try what I recommended in my previous post yet?
